Features: Excellent solvent resistance, good conformability, and surface anti-static treatment.
Applications: Used for protecting gold fingers and insulating electronic coils during PCB soldering processes, wave soldering protection, electrical insulation, high-temperature resistance, and other fields. The tape leaves no residue upon removal.
| Product Name | Product Model | Substrate Thickness (mm) | Total Thickness (mm) | Adhesion (N/25mm) | Tensile Strength (kg/25mm) | Elongation at Break (%) | Temperature Resistance (°C) | Surface Resistance Range (Ω) |
| Anti-Static Polyimide Tape | HY210-1 | 0.025 | 0.06 | 5.5 | 10-13 | 45 | 260 | 10⁶-10¹¹ |
| Anti-Static Polyimide Tape | HY210-2 | 0.050 | 0.08 | 5.5 | 20 | 55 | 260 | 10⁶-10¹¹ |
