Common Colors: Amber (black available for special orders), core sizes available in 76mm and 38mm.
Features: High-temperature resistant silicone, heat resistance, high insulation, acid and alkali resistance, low electrolysis, etc.
Applications: Used for protecting gold fingers and insulating electronic coils during PCB soldering processes, wave soldering protection, electrical insulation, high-temperature resistance, and other fields. The tape leaves no residue upon removal. Can be die-cut into various shapes when combined with PET release film for use in various electronic products.
| Product Name | Product Model | Substrate Thickness (mm) | Total Thickness (mm) | Adhesion (N/25mm) | Tensile Strength (kg/25mm) | Elongation at Break (%) | Temperature Resistance (°C) | Equivalent Foreign Product |
| Polyimide Tape | HY200-1A | 0.015 | 0.030 | 2.8 | 10 | 25-35 | 260 | |
| Polyimide Tape | HY200-1B | 0.015 | 0.035 | 3.5 | 10 | 25-35 | 260 | |
| Polyimide Tape | HY200-2A | 0.025 | 0.042 | 2.5-3.5 | 10-13 | 45 | 260 | |
| Polyimide Tape | HY200-2B | 0.025 | 0.050 | 4.0 | 10-13 | 45 | 260 | 3M98C-12 |
| Polyimide Tape | HY200-2C | 0.025 | 0.055 | 5.0 | 10-13 | 45 | 260 | |
| Polyimide Tape | HY200-2D | 0.025 | 0.060 | 5.5 | 10-13 | 45 | 260 | 3M7413D |
| Polyimide Tape | HY200-2E | 0.025 | 0.065 | 6.0 | 10-13 | 45 | 260 | |
| Polyimide Tape | HY200-2F | 0.025 | 0.070 | 6.5 | 10-13 | 45 | 260 | 3M98C-1 |
| Polyimide Tape | HY200-3A | 0.050 | 0.080 | 6.0 | 20 | 55-65 | 260 | |
| Polyimide Tape | HY200-3B | 0.050 | 0.100 | 6.5 | 20 | 55-65 | 260 | |
| Polyimide Tape | HY200-4 | 0.075 | 0.120 | 6.0 | 28 | 60-65 | 260 | |
| Polyimide Tape | HY200-5 | 0.10 | 0.15 | 6.0 | 36 | 70-75 | 260 | |
| Polyimide Tape | HY200-6 | 0.125 | 0.18 | 6.0 | 40 | 80-85 | 260 | |
| Polyimide Tape | HY200-2DA | 0.025 | 0.060 | 5.0 | 10-13 | 45 | 260 | |
| Polyimide Tape | HY200-2DB | 0.025 | 0.060 | 5.0 | 10-13 | 45 | 260 |
