Proper Use of Waterproof Tape

Waterproof tape is a self-fusing, conformable electrical insulation and waterproof sealing tape. It has strong surface adhesion and good thermal stability. It can be used for electrical insulation and waterproof sealing. Waterproof tape can be used in conjunction with PVC tape to provide reliable waterproof sealing and insulation protection for electrical circuits.

Tape Features:

Excellent conformability to irregular surfaces

Good compatibility with various cables

Self-fusing tape

Wide operating temperature range

Excellent weather resistance and waterproof sealing performance

Excellent adhesion to copper, aluminum, and cable sheath materials

Applications:

Waterproofing of joints in communication equipment base stations, antennas, and spy wires

Waterproof sealing and protection of overhead insulated conductor joints

Cable outer sheath repair

Suitable for main insulation restoration of 1000V and below

Suitable for insulation of motor leads of 1000V and below

Main insulation of busbar connections of 35KV and below

Waterproof sealing of grounding wires

To achieve optimal conformability and waterproof sealing, first remove the outer protective plastic layer of the tape before wrapping. Then stretch the tape to three-quarters of its original width. After wrapping, press the tape by hand at the wrapped area to ensure tight adhesion and no air gaps for full bonding. Finally, overlap the tape with two layers of PVC tape for mechanical protection. Waterproof connectors manufactured strictly according to the above process will generally not fail for many years. I have personally tested them in numerous projects, and there has never been a single case of failure! Wiring connectors should usually be soldered to prevent poor contact over time.
